Product Details:

Place of Origin: Zhejiang, China
Brand Name: FASEC
Certification: EN 1090-2-2018; ISO3834
Model Number: SIP555

Payment & Shipping Terms:

Minimum Order Quantity: 1000Tons
Price: USD9-USD25 Per Ton
Packaging Details: Standard Seaworthy Packings
Delivery Time: 5-8 Days Depends On The Quantity
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000000Tons
Get Best Price Contact Now

Detail Information

Material: MGO + EPS/XPS +MGO Size: 1220*2440mm
Usage: Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box Color: Yellow,Green,Pink,Grey,White,Blue
High Light:

25mm Structural Insulated Panel

,

200mm Structural Insulated Panel

,

SIP Structural Insulated Wall Panels

Product Description

Easy Installation Construction Materials OSB Board Structural Insulated Wall SIP Panel



SIPs Structural Insulated Panel (short for SIPs) is typically made by laminating expanded polystyrene between two structural skins of OSB. It's stronger, has higher insulation value and green. Building with SIPs creates an innovative, superior, energy efficient, affordable, heathier,and sustainable building envelope with high thermalresistance.



Warranty:

5 years

After-sale Service:

Online technical support, Onsite Installation, Onsite Training, Onsite Inspection

Project Solution Capability:

graphic design, total solution for projects, Cross Categories Consolidation

Application:

Hotel

Design Style:

Contemporary

Place of Origin:

Jiangsu, China

Brand Name:

LEADER/OEM

Model Number:

Mgo+EPS+Mgo(25mm-154mm)

Panel Material:

Nonmetal

Product Name:

MGO sandwich panel

Color:

Yellow,Green,Pink,Grey,White,Blue

Usage:

Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box

Material Structure:

MGO + EPS/XPS +MGO

Size:

1220*2440mm

Thickness:

25mm-200mm

Feature:

Lightweight,eco-friendly,energy-saving

Package:

wood pallets

Certificate:

CE

Fireproof:

A1



SIP PANELS (Structural Insulated Panel) is a composite building material. They consist of a sandwich of two layers of structural board with an insulating foam in between. Panel skins are magnesium oxide boards. Insulation core can be Expanded Polystyrene(EPS), Extruded Polystyrene(XPS) etc.

Characteristics and Advantages:
• Energy-saving:
Heat-insulation and preservation, keep at an invariable temperature level.
• Easy installation:
Easy to install, convenient for wire groove and water pipe inbuilt, and casual for decoration.
• Shorten construction time:
For the same construction work, 3 workers can finish within 60minuts with this panel, while for traditional brick 12 workers 60 minutes.
• Saving space:
It can averagely increase extra 4.16 m2 area for100 m2 house.
• Saving cost:
Both labor cost and construction structure cost can be greatly saved, for it’s easy installation and light weight.
• Environmental protection:
raw materials do not include any harmful substances.
• High security performance:
It has higher anti-seismic and anti-impact performance than traditional brick and other construction materials;
• Waterproof and Fire-proof
• Sound insulation



Details/Core materials EPS XPS PU Phenolic foam
Thickness 30-200mm 20-100mm 10-160mm 20-120mm
Density 15-32kg/m³ 35-47kg/m³ 36-68kg/m³ 60-75kg/m³
Color White Pink,Green,Blue,Yellow Grey etc. Pink,Yellow,Grey etc.
Thermal conductivity 0.024-0.041W/m.k 0.027-0.036W/m.k 0.02-0.024W/m.k 0.023-0.038W/m.k
Tensile strength ≥100KPa ≥350KPa ≥0.10MPa
Fire classification B3,B2,B1 B3,B2,B1 B2,B1 A
Fire resisitance       >1.6h
Formaldehyde emission       ≤1.5ml/L
Life time       15-30years



Composition Face board Core Back board
Material Mgo board EPS/XPS Mgo board
Max width 1220mm 1220mm 1220mm
Max length 3000mm 1220mm 3000mm
Thickness 3~20mm 20~150mm 3~20mm
Standard size 1220*2440mm, 1220*2400mm, 1200*3000mm

















SIP SANDWICH PANELS

• Floor System:
It’s much suitable for the floor plate of factory, workshop, warehouse, etc.
• Roof System:
Solving the problem of roof leakage, reducing the use of roof beam-column and improving security.
• Interior Partition System:
It has been widely applied to interior partition of high-rise buildings, with the advantages of excellent fire-proof, best hanging force and easy installation.
• Exterior Wall& Villa:
It’s widely applied to various modular house, low buildings, apartment, villas, and city house, etc.
