Modular Q345B Steel Frame House Kits With SIP Panel , Q235B Light Steel Prefab House
Product Details:
| Place of Origin: | Zhejiang, China |
| Brand Name: | FASEC |
| Certification: | EN 1090-2-2018; ISO3834 |
| Model Number: | FASEC-FC01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 sets |
|---|---|
| Price: | USD 180~280 per square meter |
| Packaging Details: | Standard sea shipping package, or as buyers' requirements. |
| Delivery Time: | 25~40 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 600,000 tons per Year |
|
Detail Information |
|||
| Material: | Steel | Specification: | Q235b Or Q345b |
|---|---|---|---|
| Surface Treatment: | Surface Epoxy Zinc-rich Primer Primer + Epoxy Mica Intermediate Paint | Enclosed System: | PU/EPS Sandwich Panel |
| Application: | House, School, Shopping Mall And So On | ||
| High Light: | Modular Steel Frame House Kits,Q345B Steel Frame House Kits,Q235B Light Steel Prefab House |
||
Product Description
Prefab Modular Light Steel Frame Construction House Erection with SIP Panel
The exterior wall system is generally between 120-200 mm. Due to the light and thin wall, the actual use area of the light steel structure house is about 10% - 15% more than that of the traditional house, and the indoor use area is more than 90% more than that of the traditional house. The indoor space can be flexibly separated. The pipeline can be arranged in the holes reserved in the wall, floor and roof components, with good concealment and more beautiful appearance.
1.The wall is filled with glass fiber cotton, which has good performance of heat preservation, heat insulation and sound insulation;
2.The breathing paper is waterproof and breathable, which can effectively adjust the indoor air humidity, make the living more comfortable, and effectively prevent the growth of mold inside the wall;
3.The pipeline is buried in the wall and does not occupy the indoor space.
Light steel villa floor system:
The floor is composed of high-strength hot-dip galvanized C-type and U-type light steel members. The floor beams are arranged with equal spacing and multi ribs according to the standard modulus. The floor beams are covered with structural plates which have been strictly moisture-proof and anti-corrosive, forming a strong and a seismic floor system.
1.The composite structure of structural plate and floor steel beam is firm and stable;
2.All kinds of water and electricity pipelines are concealed in the floor structure, which does not occupy the height of the building;
3.The effect of heat insulation, sound absorption and sound insulation is remarkable when glass fiber cotton is filled in the inter layer
| Item | Name | Specification |
| Standard Accessories | Ground Main Beam | H248X124X5X8,material: Q235 |
| Roof Beam | C180*70*20*3.0, material: Q235 | |
| Wall Column | square tube 70*70*3.0,material: Q235 | |
| Corner column | pressured angle steel sheet, material: Q235 | |
| Floor | wooden floor | |
| Door | colored steel sandwich panel door, size: 750mm*2000mm | |
| Window | plastic-steel window, size: 600mm*800mm |
The light steel wall structure system is a new type of green energy-saving and environmental protection building structure system, with excellent physical performance index, short construction period and good thermal insulation effect.
