Safety Residential Handrail Glass Balustrade , ISO 3834 frameless glass balcony railing
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | FESEC |
| Certification: | EN 1090-2-2018; ISO3834 |
| Model Number: | Glass Balustrade 01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 meters |
|---|---|
| Price: | USD50-200/meter |
| Packaging Details: | Cartons and plts |
| Delivery Time: | 20-38 workdays |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 5,000 Meter/ per Month |
|
Detail Information |
|||
| Product Name: | Glass Balustrade | Design Style:: | Modern |
|---|---|---|---|
| Material: | Stainless Steel+ Toughened Glass | Mounted:: | Flooring |
| Installation:: | Easy Install | ||
| High Light: | Residential Handrail Glass Balustrade,Safety Handrail Glass Balustrade,ISO 3834 Frameless Glass Balcony Railing |
||
Product Description
Customized safety residential frameless handrail glass balcony balustrade
The glass blastrade system has a wide range of uses. It is ideal for glass balconies, patio areas and terraces, and can be an effective safety handrail system. There are many options when choosing a glass railing system design.
The height of the handrail of indoor stairs, measured from the center line of the step to the upper skin of the handrail, should not be less than 900mm.
When the horizontal armrest is longer than 500mm, its height should not be less than 1000mm.
The height of the outdoor stair railing should not be less than 1050 mm, and the height of the middle and high-rise residential buildings should not be less than 1100 mm.
When the width of the stairwell is greater than 200 mm, it is not suitable to choose a lattice that is easy for children to climb.
The clearance between the vertical railings of the railing should not be greater than 110 mm.
When railings and handrails are transferred up and down or on a plane, they should be connected.
| Profile material | Carbon steel , Aluminum ,stainless steel |
| Handrail Pipe | 12.7mm ,16mm,19mm,25.4mm,31.8mm,38.1mm,50.8mm,63mm,76mm 40*40mm 50*50mm or make as buyer requirements |
| Surface | Customized |
| Application | Balcony handrail/outdoor railing/indoor handrail/indoor staircase etc |
| Height of the balustrade | 850-1200mm or customized |
| Glass fitting | Suit for single or Double tempered laminated glass or customized |
Appearance: Bright color and no fading.
Impact resistance: sturdy and durable, high impact resistance.
Long service life: One-time investment, life-long enjoyment.
High temperature resistance, low temperature resistance, salt spray resistance, and moisture resistance.
Low maintenance cost: maintenance-free and easy to clean.
Installation: modular systems for easy installation and peace of mind.
Staircase balustrade with tempered glass
Handrail: ¢50.8(diameter)x1.3mm(tube thick) ,SUS 304 ,Brush finish
Post:¢50.8(diameter)x1.3mm(tube thick) , ,SUS 304,Brush finish
Clamp for fix glass: 12mm temper glass
distance span about 1000mm
Concrete screws:M8*80mm, SUS 304 ,Brush finish
| Types of railing | Surface treatment | ||
| Standoff glass railing | diameter 50.8mm; 42.4mm; 38mm | Mirror finish | |
| Baluster glass railing | diameter 50mm/38mm circular tube baluster | Stain finish/Mirror finish | |
| 50*50/40*40/38*38mm square tube baluster | |||
| Aluminum U channel glass railing | W62*H102mm(for 10-15mm glass) W70.5*H120mm(for 19-24mm glass) W45*H120mm(for 12mm to 6+1.52 /1.14+6mm tempered laminated glass) |
Anodizing | |
| Spigot glass railing | Round: diameter 42mm, high 160mm | Stain finish/Mirror finish | |
| Baseboard diameter 100mm, 8mm | |||
| Square: 40*40mm, high 160mm; 50*50mm, high 200mm Baseboard diameter 100*100mm, 8mm |
|||
| Wire / Cable railing | Round tube baluster: 38.3; 42.4; 50.8mm | Stain finish/Mirror finish | |
| Square tube baluster: 40*40; 50*50mm | |||
| Wire: 1-16mm | |||
| Rod railing | Round tube baluster:diameter 38.1; 42.4; 50.8mm Square tube baluster:38*38; 40*40; 50*50mm Rod: diameter 8; 10; 12.7mm |
Stain finish/Mirror finish | |
| Glass Panel | 12mm Glass Panels | Glass Option | Clear,Frosted or Tinted |
| Height | 1000mm/1067mm/1100mm or customized | Mount Type | Top |
| Top Cap | diameter 38.1/42.4/50.8mm cap handrail with gasket | Compatible fixings | Wood, Metal, Concrete |
| 28*30mm cap handrail with gasket | |||
| Standard Height | 1000/1067mm/1100 to top of rail | Compatible fixings | Wood, Metal, Concrete |
| Or customized height | |||
| Stainless Steel | 304/316/316L/2205 | Glass Thickness | 10-24mm glass |
Type of balustrade:
