Product Details:

Place of Origin: Zhejiang, China
Brand Name: FASEC
Certification: EN 1090-2-2018; ISO3834
Model Number: SIP555

Payment & Shipping Terms:

Minimum Order Quantity: 1000Tons
Price: USD9-USD25 Per Ton
Packaging Details: Standard Seaworthy Packings
Delivery Time: 5-8 Days Depends On The Quantity
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000000Tons
Get Best Price Contact Now

Detail Information

Material: MGO + EPS/XPS +MGO Size: 1220*2440mm
Usage: Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box Color: Yellow,Green,Pink,Grey,White,Blue
High Light:

125mm Structural Insulated Panel


1220mm Structural Insulated Panel


Soundproof structural concrete insulated panels

Product Description

Insulation Core Sandwich Panels For Steel Warehouse Cladding EPS Sandwich Panel for Partition Use


SIPs Structural Insulated Panel (short for SIPs) is typically made by laminating expanded polystyrene between two structural skins of OSB. It's stronger, has higher insulation value and green. Building with SIPs creates an innovative, superior, energy efficient, affordable, healthier,and sustainable building envelope with high thermalresistance. It is made from both surfaces with 100% Non-Asbestos Calcium Silicate Boards( Siliceous and Calcium , such as sand, fly ash, diatomiteand, lime, calcium carbide sludge and cement) the core of natural sand, foam particle, light weight port-land cement and many additives etc.


1.Light weight,
Its density is only 750-800kg/m3, and the weight of 75mm thick wall panel is 60kg/m2, which is only 1/6 of that of brick walls, 1/2 of that of aerated concrete, and 1/7 of that of 120mm thick masonry wall with plastering on both sides.
The hanging strength of single spot is 100kg, can nail and affix tile,

3.Sound insulation,
The sound insulation capacity in the air is 35-45db( According to National standard: GBJ121-88),

4.Easy to install,
save mush cost than traditional brick construction

5.Energy saving, Environmental friendly,
The raw material do not include harmful substance.

70+ years building life span

7.Easy to be processed,
It is available for drywall partition system, saving your time and labor.Traditional sticking is suitable for it. Besides, these boards can be worked with lacquering, glue, bonding, punching, cutting, screwing, contour, cutting, routing.

8.Low density,

9. Fire-resistance,
It can endure fire at 1000 degrees for over 4 hours, without producing any toxic gas.

                                                                                                                                                                                                                                    10.Fungus resistant, moisture-proof,


b. Application:

1.Interior Partition(Thickness: 50mm, 75mm, 100, 125mm)

2.Exterior Wall (Thickness: 125mm, 150mm),

3.Modern high-rise building,
The indoor space of ecological residences and all kinds of houses and structures, etc.


Soundproof 1220mmx2440mm 125mm Structural Insulated Panel 0

Technical Specification of Thaibeck Sandwich Board
Standard Thickness Length Width Reference weight Tolerance
50 Series 50mm 2440mm 610mm 40kg/m2 Length:±5mm
Width:±2mm Thickness:±1mm
Flatness: ±2mm
75 Series 75mm 2440mm 3000mm 60kg/m2
100 Series 100mm 78kg/m2
125 Series 125mm 90kg/m2
150 Series 150mm 105kg/m2
Item Unit 150mm 125mm 100mm 75mm 50mm
Dry Shrinkage mm/m 0.35 0.35 0.36 0.35 0.36
Sound Insulation dB ≥52 ≥50 ≥46 ≥43 /
Anti-impact Times of no
through cracking
10 10 10 10 10
Destroy Loading The multiple of the board's self-weight (loading) 3.5 3.5 4 4.5 4.2
Compressive Strength Mpa 3.6 3.6 3.7 3.7 4.2
Hanging Strength N 1000 1000 1000 1000 800
Fire Rating H ≥3 ≥3 ≥3 ≥2 1
Heat Transfer Coefficient W/(m 2 @K) 1.45 1.25 1.25 - -
Moisture Content % 10 10 10 10 10
Moistureproof Moistureproof
In-Combustibility GB8624-2006 Grade A1
Resistance to Halide Moistureproof & Halide Resist
Gas proof and anti-moth Inorganic substances have insect-resistant, gas proof and anti-moth performance
