Prefabricated Villa ISO 3834 Steel Frame House Kits
Product Details:
Place of Origin: | Zhejiang, China |
Brand Name: | FASEC |
Certification: | EN 1090-2-2018; ISO3834 |
Model Number: | FASEC-FC01 |
Payment & Shipping Terms:
Minimum Order Quantity: | 5 sets |
---|---|
Price: | USD 180~280 per square meter |
Packaging Details: | Standard sea shipping package, or as buyers' requirements. |
Delivery Time: | 25~40 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 600,000 tons per Year |
Detail Information |
|||
Material: | Steel | Specification: | Q235b Or Q345b |
---|---|---|---|
Surface Treatment: | Surface Epoxy Zinc-rich Primer Primer + Epoxy Mica Intermediate Paint | Enclosed System: | PU/EPS Sandwich Panel |
Application: | House, School, Shopping Mall And So On | ||
Highlight: | ISO 3834 Steel Frame House Kits,ISO3834 Prefabricated Steel Frame House Kits,ISO3834 Villa prefabricated house kits |
Product Description
Prefabricated Light steel structure villa luxury light steel frame villa house kit
Light steel villas are characterized by safety, comfort and fast construction speed. Because the heavy structure is a light steel structure and the shape is particularly beautiful, this new type of house is called a light steel villa.
Light steel villa, also known as light steel structure house, its main material is light steel keel synthesized from hot-dip galvanized aluminum steel strip through cold rolling technology.
Prefabricated Light steel structure villa luxury light steel frame villa house kit | ||
Main Steel Frame | Column&Beam | Q235,Q345 Welded H Section Steel |
Secondary Frame | Purlin | Q235 C&Z purlin |
Knee brace | Q235 Angle Steel | |
Tie Rod | Q235 Circular Steel Pipe | |
Brace | Q235 Round Bar | |
Vertical&Horizontal Support | Q235 Angle Steel,Round Bar or Steel Pipe | |
Maintenance system | Roof Panel | EPS/Glass Fiber/Rockwool/PU Sandwich Panel or Steel Sheet |
Wall Panel | Sandwich Panel /Corrugated Steel Sheet | |
Accessories | Window | Aluminium Alloy/PVC/Sandwich Panel |
Door | Sliding Sandwich Panel door/ Rolling Metal door | |
Rain spout | PVC | |
Live load on roof | 50kg/Sqm(According to your request) | |
Wind Resistance Grade | 12 Grades | |
Earthquake-resistance | 8 Grades | |
Structure Usage | UP to 50 years | |
Temperature | Suitable temperature:-50ºC~+50ºC | |
Options | Vast array of colors and textures availiable | |
Paint Options | Alkyd paiting,two primary painting,one finish painting(gray, red, blue,epoxy zinc etc) or Galvanized |
The wall structure system of the light steel villa is composed of light steel multi-ribbed beams and columns and the maintenance structure. It has excellent physical performance indicators, short construction period, and good thermal insulation effect. It is a new type of green, energy-saving and environmentally friendly building structure system.
