Product Details:

Place of Origin: CHINA
Brand Name: FASEC
Certification: EN 1090-2-2018; ISO3834
Model Number: Stair Guardrail 02

Payment & Shipping Terms:

Minimum Order Quantity: 10 meters
Packaging Details: Cartons and plts
Delivery Time: 20-38 workdays
Payment Terms: T/T, L/C
Supply Ability: 5,000 Meter/ per Month
Get Best Price Contact Now

Detail Information

Product Name: Stair Guardrail Design Style:: Modern
Material: Stainless Steel+ Toughened Glass Mounted:: Flooring
Installation:: Easy Install
High Light:

Clear Tempered Glass Stair Handrail Guardrail


Height 1200mm Stair Handrail Guardrail


ISO3834 Stair Handrail Guardrail

Product Description

Name: Stair Guardrail
Beautiful and generous, make the guardrail look more atmospheric!
Colors can be arbitrarily matched according to requirements
Stylish and simple, highlighting individuality
Easy to install, light and flexible, good permeability
Scope of application:
Municipal construction and corporate plant
Residential complexes and high-end villas
Tourist attractions and garden nurseries
Isolation and protection of sports venues and general venues
The glass blastrade system has a wide range of uses. It is ideal for glass balconies, patio areas and terraces, and can be an effective safety handrail system. There are many options when choosing a glass railing system design.
The height of the handrail of indoor stairs, measured from the center line of the step to the upper skin of the handrail, should not be less than 900mm.
When the horizontal armrest is longer than 500mm, its height should not be less than 1000mm.
The height of the outdoor stair railing should not be less than 1050 mm, and the height of the middle and high-rise residential buildings should not be less than 1100 mm.
When the width of the stairwell is greater than 200 mm, it is not suitable to choose a lattice that is easy for children to climb.
The clearance between the vertical railings of the railing should not be greater than 110 mm.
When railings and handrails are transferred up and down or on a plane, they should be connected.


Profile material Carbon steel , Aluminum ,stainless steel
Handrail Pipe 12.7mm,16mm,19mm,25.4mm,31.8mm,38.1mm,50.8mm,63mm,76mm 40*40mm 50*50mm or make as buyer requirements
Surface Customized
Application Balcony handrail/outdoor railing/indoor handrail/indoor staircase etc
Height of the balustrade 850-1200mm or customized
Glass fitting Suit for single or Double tempered laminated glass or customized

Appearance: Bright color and no fading.
Impact resistance: sturdy and durable, high impact resistance.
Long service life: One-time investment, life-long enjoyment.
High temperature resistance, low temperature resistance, salt spray resistance, and moisture resistance.
Low maintenance cost: maintenance-free and easy to clean.
Installation: modular systems for easy installation and peace of mind.
Staircase balustrade with tempered glass
Handrail: ¢50.8(diameter)x1.3mm(tube thick) ,SUS 304 ,Brush finish
Post:¢50.8(diameter)x1.3mm(tube thick) , ,SUS 304,Brush finish
Clamp for fix glass: 12mm temper glass
distance span about 1000mm
Concrete screws:M8*80mm, SUS 304 ,Brush finish
 Clear Tempered Glass Railing Stair Handrail Guardrail Easy Installation 0
 Clear Tempered Glass Railing Stair Handrail Guardrail Easy Installation 1


Types of railing Surface treatment
Standoff glass railing diameter 50.8mm; 42.4mm; 38mm Mirror finish
Baluster glass railing diameter 50mm/38mm circular tube baluster Stain finish/Mirror finish
50*50/40*40/38*38mm square tube baluster
Aluminum U channel glass railing W62*H102mm(for 10-15mm glass)
W70.5*H120mm(for 19-24mm glass)
W45*H120mm(for 12mm to 6+1.52
/1.14+6mm tempered laminated glass)
Spigot glass railing Round: diameter 42mm, high 160mm Stain finish/Mirror finish
Baseboard diameter 100mm, 8mm
Square: 40*40mm, high 160mm; 50*50mm, high 200mm
Baseboard diameter 100*100mm, 8mm
Wire / Cable railing Round tube baluster: 38.3; 42.4; 50.8mm Stain finish/Mirror finish
Square tube baluster: 40*40; 50*50mm
Wire: 1-16mm
Rod railing Round tube baluster:diameter 38.1; 42.4; 50.8mm
Square tube baluster:38*38; 40*40; 50*50mm
Rod: diameter 8; 10; 12.7mm
Stain finish/Mirror finish
Glass Panel 12mm Glass Panels Glass Option Clear,Frosted or Tinted
Height 1000mm/1067mm/1100mm or customized Mount Type Top
Top Cap diameter 38.1/42.4/50.8mm cap handrail with gasket Compatible fixings Wood, Metal, Concrete
28*30mm cap handrail with gasket
Standard Height 1000/1067mm/1100 to top of rail Compatible fixings Wood, Metal, Concrete
Or customized height
Stainless Steel 304/316/316L/2205 Glass Thickness 10-24mm glass

Detail of Stair Guardrail :
Clear Tempered Glass Railing Stair Handrail Guardrail Easy Installation 2
Clear Tempered Glass Railing Stair Handrail Guardrail Easy Installation 3
