Sun Shading 6mm 6A/9A/12A 6mm Glass Curtain Wall Facade
Product Details:
| Place of Origin: | Zhejiang, China |
| Brand Name: | Fasecbuildings |
| Certification: | EN 1090-2-2018; ISO3834 |
| Model Number: | Hidden Frame |
Payment & Shipping Terms:
| Minimum Order Quantity: | 300 sqm |
|---|---|
| Price: | USD400-1200 per sqm |
| Packaging Details: | Seaworthy packing in container or bulk vessel |
| Delivery Time: | Based on client's needs like one month |
| Payment Terms: | L/C,T/T, D/A, D/P, Western Union |
| Supply Ability: | 600,000 sqm per Year |
|
Detail Information |
|||
| Specification: | Low-E Glass | Material: | Steel And Glass |
|---|---|---|---|
| Color: | Customized As Order | Installation: | Very Easy |
| Size: | According To Client's Need | Application: | Commercial Building |
| High Light: | 6mm Glass Curtain Wall Facade,9A Glass Curtain Wall Facade,12A glass wall facade |
||
Product Description
Sun-shading 6mm + 12A+ 6mm Low-E Glass Curtain Wall Energy Saving
Product description:
Sun-shading Low-E glass is a kind of glass that the strong light of the sun is blocked outdoors by the setting of the Low-E film. The visible light transmittance of Low-E glass ranges from theoretically 0%-95% (which is difficult to achieve with 6mm white glass), and the visible light transmittance represents indoor lighting. The outdoor reflectance is about 10%-30%. The outdoor reflectance is the visible light reflectance, which represents the intensity or dazzling degree of the light. So far, China requires that the visible light reflectance of the curtain wall is no more than 30%. The above-mentioned characteristics of Low-E glass have made it increasingly widely used in developed countries.
Specification:
| Glass composition | Float glass, laminated glass, tempered glass,low-E glass,tinted glass etc. |
| Thickness | 1)Aluminum Strip Width:6A,9A,12A,15A,17A,19A 2)Glass Thickness:3mm -19mm Normal sizes: 4mm+6A/9A/12A+4mm; 6mm+6A/9A/12A+6mm 8mm+6A/9A/12A+8mm etc. 3) As customer's requirements. |
| Size | 1)Max size: 3000mm x 8000mm Min size:200mmx200mm 2)According to the customer requirements |
| Color | Clear,white,bronze,blue,gray, green, dark green, F-green, sapphire blue, ocean blue, bron |
| Shape | 1)semi-circle 2)rectangle 3)arch 4)special shape |
| Filled Gas | 1) air 2) vacuum 3) argon, etc. |
Advantage:
1. It can block the strong outdoor light, but the visible light can pass through appropriately;
2. The solar transmittance is relatively moderate, but it can greatly reduce the solar heat radiation entering the room;
3. High reflectivity for mid- and far-infrared rays, effectively preventing the secondary heat radiation from entering the room.
Application:
1. It is suitable for areas with hot summers and cold winters. The reason is that in the winter in the north, although this kind of glass can restrict part of the solar heat from entering the room, it can well prevent the heat generated by the indoor heating equipment from flowing out. The summers in Australia and North America are hot, and refrigeration equipment is installed indoors. This kind of glass can reduce the entrance of solar heat into the room, and can also reduce the extravasation of air-conditioning air-conditioning. Therefore, from the perspective of energy saving effect, the sun-shading Low-E glass is no less than the high-transmitting Low-E glass, and it is suitable for both summer and winter;
2. The scope of application is very wide, both decorative and covering.
