Product Details:

Place of Origin: China
Brand Name: FASEC
Certification: EN 10902:2018, EN ISO 38342:2005, SMK41275
Model Number: Fasec 512051

Payment & Shipping Terms:

Minimum Order Quantity: 1 tons
Price: US$2000-5000
Packaging Details: 1.Wrap with shrink film exterior; 2. PE shrink film; 3. Packed according to customer reques.
Delivery Time: 20-35 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 kgs / week
Get Best Price Contact Now

Detail Information

Temper: T3-T8, T5, T5 T6, T6, T4 Grade: 6000 Series, Other, 6063/6061/6005/6060 T5/T6, 6063 Aluminum Alloy
Shape: Square, Flat, Angle, Customized, T - Profile Application: Door & Window, Decorations, Workbench, Workstations, Automobile
Surface Treatment: Anodize, Polishing, Powder Coated, PVDF Coating/Power Coating/Colored Anodize, Powder Coating Color: Silver, Blue, Any Color, Black, Sliver
High Light:

Casement Aluminium Door Profile


Window Wall Anodized Aluminum Profile


Extrusion Aluminium Door Profile

Product Description

Why Choose Aluminium Windows Profiles


Aluminum window frames are cost-effective, sturdy and durable, while at the same time having functionality and versatility as well as a stylish modern style.

Aluminum window profiles provide highly durable and cost-effective solutions for residential and commercial buildings. They require almost no maintenance, can be used for life, will not rust, and even have a high corrosion resistance limit.

Aluminum window profiles can be provided in standard sizes, and can also be manufactured in customized sizes and styles to meet your specific requirements.

It is also nice to know that your aluminum alloy window frame can be equipped with various types of functional glass. This includes safety protective glass, aesthetic glass, soundproof glass, fireproof glass and bulletproof glass. They can also be double-glazed to provide higher energy efficiency, better acoustics and many other benefits, bringing comfort and security to your house.

The Production Process of Aluminum Window Profile

1. Ingot casting

The process contains the ingredients, melting, casting, homogenization. This is the main process of certain chemical composition and size of the ingot.

2. Extrusion

Extrusion includes an automatic production line composed of ingot heating, extrusion, cooling, straightening, cutting and other processes.

The ingot heating temperature is controlled at 400℃~520℃, too high or too low will directly affect the extrusion.

3. Heat treatment

Through different systems for quenching and aging treatment to obtain the mechanical properties of the profile. Aluminum profile aluminum windows provide materials in RCS state, that is, high temperature heat treatment and rapid cooling are performed after molding and artificial aging.

4. Surface treatment

The most common steps are anodizing, electrophoresis, powder coatings and fluorocarbon coatings so that the surface can have different colors and good appearance. Surface treatment can enhance the aesthetic appearance of the profile and prolong the service life of the aluminum window profile.


Finished Projects

Window Wall Extrusion Aluminum Profile Casement Aluminium Door Profile 0

Material Selection


Aluminum Frame 50 series, 55 series, 60 series,70 series ,80 series ,85 series, 90 series,100 series and so on.
Glass Panels

a. Single tempered glass: 8/10/12mm tempered glass
b. Laminated Glass: 13.52mm/ 17.52mm/21.52mm/25.52
c. Insulated Glass: 6+12A/16+6mm / 8+12A/16A+8mm /8+12A/16A+13.52mm (Low-e glass/ reflective glass)

d.Triple glazing glass: 6+16A+6+16A+6mm/ 8+18A+6+16A+6mm (Low-e glass / reflective glass)


What can we do?


Window Wall Extrusion Aluminum Profile Casement Aluminium Door Profile 1




Window Wall Extrusion Aluminum Profile Casement Aluminium Door Profile 2


If you have interest, please contact us for a quote. We are happy to talk about estimates and solutions for your project.
